Description
ASUS Prime AP303 Tempered Glass Panel Stylish Mid-Tower with High Airflow
Design & Materials
The Prime AP303 with tempered glass panel is a thoughtfully engineered mid-tower ATX case that combines high airflow and premium aesthetics. With sleek design elements and a roomy internal layout, it supports a full-size desktop build without taking up excessive space.
The front and left side panels feature metal mesh to maximize airflow while preventing dust buildup.
The right-side panel is made from thick tempered glass, offering a clear view of your internal components for a visually appealing build.
A built-in bracket supports long graphics cards (up to 360 mm), and a GPU support bracket helps prevent sag while maintaining stability.
Cooling & Thermal Support
Storage & Cable Management
Fan support: Up to 7 fans three 120/140 mm fans on top, three 120/140 mm on the front, and one 120 mm rear.
Radiator support: Top mounts support 120 / 140 / 240 / 280 / 360 mm radiators, and the rear supports 120 mm.
CPU cooler height: Up to approximately 165 mm.
Power supply: Supports ATX PSUs up to 180 mm in length.
Drive bays: Offers space for 2 × 2.5? SSDs plus 1 × 2.5? or 3.5? HDD/SSD.
Cable routing: 34 mm of clearance behind the motherboard for clean cable management and airflow optimization.
Front I/O & Connectivity
Dimensions & Build Quality
Ports include 2 × USB 3.2 Gen 1 Type-A and a USB 3.2 Gen 2×2 Type-C port (20 Gbps), making it easy to connect high-speed peripherals.
Also includes a combo headphone/microphone jack.
Tool-free panel latches simplify access to internal components for upgrades or maintenance.
Form factor: Mid-tower ATX
Approximate size: 215 mm (W) × 425 mm (H) × 485 mm (D)
Weight: Around 7.8 kg for the tempered-glass model
| Model No | Prime AP303 Tempered Glass Panel |
| Part No | 90DC00V0-B39010 |
| Color | Black |
| Case Material | Steel & ABS plastic with tempered glass panel |
| Case Size / Volume | Compact mid-tower (44 L) |
| Lighting | None (no built-in RGB) |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX |
| Pre-installed Fans | 1 × 120 mm (rear) |
| Additional Fan Support | Top: up to 3 × 120 mm or 3 × 140 mm Rear: 1 × 120 mm |
| Radiator Support | Top: 120 / 140 / 240 / 280 / 360 mm Rear: 120 mm |
| SSD / HDD Support | 2 × 2.5? + 1 × 2.5? / 3.5? combo bay |
| I/O Ports | 1 × Headphone / Mic combo, 2 × USB-A (USB 3.2 Gen 1), 1 × USB-C (USB 3.2 Gen 2×2) |
| CPU Cooler Height Limitation | Up to 165 mm |
| Graphics Card (VGA) Length Limitation | Up to 360 mm |
| PSU (Power Supply) Limitation | Up to 180 mm |
| Dust Filters | Removable dust filter at bottom |
| Maximum Cable Management Space | ~34 mm behind motherboard tray |
| Dimensions (W × H × D) | 215 × 425 × 485 mm |
| Product Weight | ~7.8 kg (tempered glass edition) |
| Package Contents | Case, accessories pack (screws, brackets), user manual |
| Warranty | 1-year limited hardware warranty |
