Description
Premium Build & Visual Impact
The Hyperion GR701 BTF Edition brings high?end materials and striking aesthetics to your gaming rig. With an aluminium?reinforced frame, steel chassis and dual tempered?glass side panels, this full?tower case is built not only to show off your components but also to endure heavy hardware. The bold ROG?themed exterior and integrated ARGB lighting panels elevate the look, giving your system a refined, futuristic presence.
Unrivalled Cooling & Expansion Support
Smart Features for Clean Builds & Future?Proofing
This case is designed for serious performance. It supports massive graphics cards up to 460 mm in length and CPU coolers up to 190 mm tall. The cooling options are deep: you can install dual 420 mm radiators (front and top), and it comes with pre?installed large 140 mm fans plus a dedicated ARGB/fan hub for further expansion. All of this means your build stays cool even under demanding workloads or high?end gaming.
Beyond raw size and cooling, the Hyperion GR701 BTF emphasizes practicality and clean aesthetics. It features tool?free hinged glass panels, a built?in graphics?card support bracket, expansive cable?management channels (34 mm depth, 46 mm width), and dual front USB?C ports including fast?charging capability. Designed for the Back?To?Future (BTF) ecosystem, it helps hide and streamline wiring to give your build a polished, professional finish.
Specifications :
Form Factor: Full Tower
Motherboard Support: ATX, E-ATX, Micro-ATX, Mini-ITX
Material: Aluminum frame, Steel chassis, Tempered glass (both sides), ABS plastic
Pre-installed Fans: 4 x 140mm ARGB fans
Cooling Support: Up to 2 x 420mm radiators (top & front), 9 total fan mounts
GPU Clearance: Up to 460mm
CPU Cooler Clearance: Up to 190mm
PSU Support: ATX (up to 220mm)
Drive Bays: 2 x 3.5″ HDD, 6 x 2.5″ SSD
Front I/O Ports:
2 x USB 3.2 Gen 2 Type-C
4 x USB 3.2 Gen 1 Type-A
1 x 3.5mm combo audio jack
Cable Management: 34mm depth, 46mm width
Special Features: Tool-free hinged glass panels, ARGB/fan hub, GPU support bracket, BTF-ready (hidden connector design)
Color: Black
| Model No | Hyperion GR701 BTF Edition |
| Part No | 90DC00F0-B39020 |
| Color | Black / Transparent (tempered glass sides) |
| Case Material | Aluminum alloy frame, tempered glass panels, steel structure |
| Case Size / Type | Full Tower |
| Lighting | ARGB lighting support with Aura Sync, integrated (ARGB fan hub) |
| Motherboard Support | E-ATX (12″ × 10.9″), ATX, Micro-ATX, Mini-ITX |
| Pre-installed Fans | 4 × 140 mm PWM ARGB fans (3 front + 1 rear) |
| Additional Fan Support | Front: up to 3 × 120/140 mm Top: up to 3 × 120/140 mm Rear: 1 × 120/140 mm |
| Radiator Support | Front: up to 420 mm Top: up to 420 mm Rear: up to 140 mm |
| SSD / HDD Support | 5 × 2.5? drives 2 × 2.5? / 3.5? combo bays |
| I/O Ports | 4 × USB 3.2 Gen 1 Type-A 1 × USB 3.2 Gen 2 Type-C 1 × USB 4.0 Type-C or 1 × USB 3.2 Gen 2×2 Type-C (region variant) Headphone / microphone combo jack LED control / reset buttons |
| CPU Cooler Limitation (Max Height) | 190 mm |
| VGA (GPU) Limitation (Max Length) | 460 mm |
| PSU Limitation (Max Length) | 240 mm |
| Dust Filters | Removable filters at Front, Top, and Bottom |
| Product Size (Dimension) | 268 mm × 639 mm × 659 mm |
| Product Weight | ~20.8 kg (21.3 kg in some listings) |
| Package Content | Case & Cables |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
